Single-Capacitor Active-Feedback Compensation with Feedforward Stage
-
- Englisch ausgewählt
Fr. 55.90
inkl. gesetzl. MwSt.,
Beschreibung
Produktdetails
Einband
Taschenbuch
Erscheinungsdatum
25.07.2013
Verlag
LAP LAMBERT Academic PublishingSeitenzahl
76
Maße (L/B/H)
22/15/0.6 cm
Gewicht
131 g
Sprache
Englisch
ISBN
978-3-659-43521-8
Multistage amplifiers with high dc gain, a wide gain-bandwidth product, a large output signal swing are widely used in analog signal processing systems. Due to the scaling in CMOS technologies, single-stage cascade amplifier is no longer suitable in low-voltage designs. Therefore, many frequency compensation topologies based on Miller pole splitting and pole-zero cancellation has been reported to stabilize the multistage amplifiers. Single-Capacitor Active- Feedback Compensation with Feedforward Stage (SCAFC-FFS) scheme is proposed for three-stage amplifiers driving small capacitive loads. With the small-value compensation capacitor, high dc gain, a wide gain-bandwidth product and increased slew-rate can also be achieved under low-power conditions. The frequency compensation scheme is investigated and verified by PSPICE.
