Conceptual Design ICRH Antenna Support Structure For the DTT Nuclear Fusion Machine.DE
-
- Englisch ausgewählt
Fr. 67.90
inkl. gesetzl. MwSt.,
Beschreibung
Produktdetails
Einband
Taschenbuch
Erscheinungsdatum
06.05.2026
Verlag
Our Knowledge PublishingSeitenzahl
56
Maße (L/B/H)
22/15/0.4 cm
Gewicht
102 g
Sprache
Englisch
ISBN
978-620-9-94576-2
The text describes an "innovative" support for the ICRH antenna for the DTT, redesigned to respect space constraints, support 40 tons, and limit displacement to less than 1 mm.The original tubular structure was too deformable (2 mm). After several attempts with IPE and HEA/HEB sections, the optimal solution was identified in HEB 120 beams.The final version, completely bolted to improve maintenance, was verified with FEM analysis: the maximum displacement is 0.69 mm and the stresses are within the limits.The structure thus satisfies all requirements and is ready for integration into the DTT system.
