Arif Sobhan Bhuiyan, M: Wireless Multi Meter Design, Construction and Implementation
-
- Englisch ausgewählt
Fr. 62.90
inkl. gesetzl. MwSt.,
Beschreibung
Produktdetails
Einband
Taschenbuch
Erscheinungsdatum
11.03.2012
Verlag
LAP LAMBERT Academic PublishingSeitenzahl
80
Maße (L/B/H)
22/15/0.5 cm
Gewicht
136 g
Sprache
Englisch
ISBN
978-3-8484-1205-1
A wireless multimeter is an instrument used to measure the current, voltage, frequency and apparent power at a load from a distance. In this project a wireless multimeter was designed which consisted of two major parts: 1) Measuring Section Module and 2) Remote Display Module. Measuring Section Module consisted of three major section which are i) signal input, ii) Micro controller, iii) RF transmitter whereas the remote display module also consisted of three parts i) RF Receiver, ii) Microcontroller and iii) LCD Display Module. After all relevant calculations the dc voltage produced by the micro controller was sent through an RF Frequency transmitter module having an omnidirectional antenna. The RF receiver module situated at a maximum distance of 150 meters from the transmitter, received the transmitted data. The result is then displayed through a 16-bit LCD display module. This multimeter was found to measure the values of the voltage, current, power and frequency ranging from (0-250)V, (0-20)A, (0-5000)VA and (0-125)KHz respectively. The main attraction of our designed circuit was the simplicity of the circuit, easiness of implementation and the availability of components.
