Study and Analysis of 2.4 GHz Low Noise Amplifier Characterization of 2.4 GHz Low Noise Amplifier
-
- Englisch ausgewählt
Fr. 55.90
inkl. gesetzl. MwSt.,
Beschreibung
Produktdetails
Einband
Taschenbuch
Erscheinungsdatum
28.08.2014
Herausgeber
Ram KumarVerlag
LAP LAMBERT Academic PublishingSeitenzahl
60
Maße (L/B/H)
22/15/0.5 cm
Gewicht
107 g
Sprache
Englisch
ISBN
978-3-659-59524-0
The concept of the RFIC design needed for the design of low noise amplifier such as gain, noise, stability, linearity, power consumption etc is discussed in the report. An overview has been given on different LNA architecture, their advantages and disadvantages have also been discussed.In this thesis the design and analysis of a low noise amplifier at 2.4GHz frequency has been discussed. We used cascode source degeneration topology for this design because this is provides some significant advantages over other topologies. The designed circuit is simulated with the help of spectre simulator from cadence design system using UMC .18um CMOS technology. After the simulation we got the simulated result of low noise amplifier as forward voltage gain(S21) of 24.3dB, noise figure is 1.8dB and minimum noise figure is 1.6dB, input reflection coefficient (S11) is -25.83dB, stability factor (Kf) is 4, third order intercept point(IIP3) is - 9.06dBm by using power supply voltage of 1.8v.
